Features

DT-9915/9915T

DT-9916

DT-9917/9917T

DT-9918/9918T

Digital display counts

4000

4000

4000

4000

True RMS measurement

DT-9915T

DT-9917T

DT-9918T

Safety design

*

*

*

*

Relative zero

*

*

*

Data Hold

*

*

*

*

MAX/MIN recording mode

Auto Power Off

*

*

*

*

Peak capture mode

*

Wide capacitance range

20mF

*

Current DC/AC 40µA

*

Analog bargraph/segment

*

Specifications

Function

Max. Range

Basic Accuracy

DT-9915/9915T

DT-9916

DT-9917/9917T

DT-9918/9918T

Voltage DC

1000 V

±0.5%

*

*

*

*

Voltage AC

1000 V

±0.8%

*

*

*

*

Current DC

10A

±1.2%

*

*

*

*

Current AC

10A

±1.8%

*

*

*

*

Resistance

40MΩ

±0.8%

*

*

*

*

Duty Cycle

99.90%

±1.2%

*

*

*

Frequency

10MHz

±1.5%

*

*

*

Capacitance

200 µ F/40mF

±3.0%

200µF

20mF

200µF

40mF

Temperature

760ºC/1400ºF

±3.0%

*

*

Diode Check

*

*

*

*

Continuity Test

*

*

*

*
